Comprehensive Guide to RFID Range

RFID has become indispensable in many sectors. You'll find RFID technology used in inventory, asset tracking, and access control. When choosing a system for your business, it is important to understand the RFID range. Our guide has been written to help you understand tag distance, from short to long, so that you can select the right system for your business needs..

Technical specifics of RFID systems

RFID (Radio Frequency Identification) is used to automatically identify and track objects. The RFID technology uses electromagnetic fields. RFID systems have three main components: an RFID tag, a reader and an antenna. These components are essential. They enable contactless transmission, allowing the system to locate, track and trace objects.

Understanding RFID frequencies

RFID technology uses radio waves to transmit data between the tag and the reader. There are three types of frequencies used in RFID technology: ultra-high frequency (UHF), high-frequency (HF) and low-frequency (LF). Let's look at the differences between them.

Ultra-high frequency (UHF)

Ultra high frequency systems are mainly used in retail, logistics, pharmaceuticals, and warehouse management. Typically, the UHF range is between 300 MHz and 3 GHz. RFID systems operate at frequencies between 856 MHz and 960 MHz. An ultra-high frequency RFID reader can have a range of over 10 metres. UHF systems allow very fast data transmission. UHF RFID tags are commonly used in logistics, personnel tracking and asset management. It covers large areas and provides efficient data collection.

High-frequency (HF)

Typically, the HF range between 3 and 30 MHz. RFID high-frequency systems operate at frequencies 13.56 MHz. A high-frequency systems RFID reader can have a range of 10 cm to 1 m. High-frequency RFID is mainly used in payment systems, transport cards and access cards.

Low-frequency (LF)

Typically, LF range between 1Hz and 100 kHz. Low-frequency systems operate at frequencies between 125 kHz and 134.2 kHz. Low-frequency systems allow for less than 10 cm. LF RFID is used in access control systems and animal identification.

Active RFID range or passive RFID range?

Once again, the choice between active and passive RFID depends mainly on your business needs..

Active RFID tag

An active RFID tag has a longer range than a passive RFID tag. An active tag is powered by an internal battery and usually operates in the ultra-high frequency band 433MHz and 96 MHZ. It continuously transmits signals to an RFID reader up to 150 metres away.

Passive RFID tag

A passive RFID tag is powered by the RFID reader. It has a shorter range of up to 10 metres or less. Passive RFID systems can operate in the low-frequency (LF), high-frequency (HF) and even the ultra-high frequency (UHF) radio bands

Practical applications of RFID technology

As mentioned above, RFID technology has become indispensable in many sectors. Its efficiency allows companies to automate many tasks, to improve performance and reduce tracking and management errors.

How RFID improves asset management and inventory control

---

RFID technology improves asset management and inventory control through automatic inventory and tracking. Unlike barcodes, RFID tags do not require a "line-of-sight", you can read the tag from a distance with an RFID reader. This speeds up inventory processing. RFID tags are attached to products and can be read and updated in real time throughout the supply chain, providing greater visibility of inventory locations.

Key points for optimising the RFID tag

---

You'll need to consider the environmental factors that can affect the range of your RFID label.

• The first key to consider is materials and surfaces. Be aware that metal surfaces can reflect RFID signals. Liquids, on the other hand, can absorb signals. You should always use tags that are specifically designed for your working environment.
• The second key is to consider the temperature and the humidity. Both can affect the tags and the readers.
• The last key is electromagnetic interference. Other electronic devices can affect the read range of RFID systems. Optimising the RFID antenna design can reduce interference.

Comparative analysis of RFID and NFC frequency ranges

Let's look at the differences between low-frequency, high-frequency, ultra-high frequency and near-field communication.

Difference between UHF, HF, LF ranges and NFC

Let's compare the different RFID frequencies. Low-frequency has low energy, it transmits data more slowly and has a limited range. The size of the tag's antenna is usually large enough for a longer distance. Although shorter than higher frequencies, it is more tolerant of obstructions. Ultra-high frequency and high-frequency have more energy and can be used for long-range applications. However, they are more sensitive to interference. Since high-frequency and ultra-high frequency have more energy, they allow faster data transmission.

You'll find NFC technology in most smartphones. This technology is a proximity-based wireless communication standard. The interaction with NFC is limited to an extremely short range. You can also find NFC on tablets, collectibles or game consoles. The main difference between RFID and NFC is that RFID can receive and transmit radio waves over greater distances. NFC is limited, with a range of 0 to 5 cm.

Table comparing UHF, HF, LF ranges and NFC
