Product Highlights

  • Printer Compatibility:

    BMP41, BMP51, BMP53, M410, M510, M511

  • Max. Wire/Cable Diameter (mm):

    6.35 mm

  • Size - Height (mm):

    50.80 mm

  • Size - Width (mm):

    25.40 mm

  • Brady Material No.:

    B-483A (View Technical Data Sheet)

  • Brady Material Type:

    Polyester

  • Colour:

    Black on White

Add To Compare In Compare

Order Reference:

M4-214-483

Contact Customer Service

Overview

Quickly flag wires and cables with the B-483 QuickFlag™ label material, featuring a tapered design to prevent mismatched edges. Print almost anywhere with a Brady portable label printer.

  • Specialised — Patent pending designed with a tapered adhesive side to create easy-to-apply one-sided wire and cable flags without mismatched edges or exposed adhesive
  • Durable — Made with a tough polyester material that resists abrasions, temperatures of -40 to 120° C, and solvents such as fuel, oil and water
  • Adhesive — Made with an ultra-aggressive rubber-based adhesive on the tapered side for permanent use
  • Certified — UL Recognised to UL969, CSA accepted, RoHS Compliant to 2011/65/EU (Pass 2015/863)
  • For material specific performance and properties, please refer to the Technical Data Sheet (TDS)

Specifications

Key Characteristics
Key Characteristics Minimum Order Quanitity 1
Article Number 170965
Order Reference M4-214-483
Total Qty per Pack 140 Label(s) / Box
Application(s) Asset tracking, Barcode labelling, Component and equipment labelling, Data and telecommunications labelling, Electrical labelling, General identification, Inventory and inspection labelling
Quantity 140
Brand Brady®
Trade Name QuickFlag™
Qty per Roll 140
Ribbon Series R6000HF
Country of Origin Mexico
Country of Origin (SAP) MX

Dimensions
Dimensions Size - Width (mm) 25.40 mm
Size - Height (mm) 50.80 mm
Max. Wire/Cable Diameter (mm) 6.35 mm
Min. Wire/Cable Diameter (mm) 1.52 mm
Wire Diameter Range (mm) 1,52 mm - 6,35 mm
Printable Area Dimensions 25,40 mm W x 25,40 mm H
Printable Area - Height (mm) 25.40 mm
Printable Area - Width (mm) 25.40 mm
Vertical Repeat (mm) 53.98 mm
Web Width (mm) 33.32 mm
Dimensions 25,40 mm (W) x 50,80 mm (H)

Material Characteristics
Material Characteristics Brady Material No. B-483A (View Technical Data Sheet)
Brady Material Type Polyester
Thickness (mm) 0.102 mm
Colour Black on White
Max. Service Temp. °C 120 °C
Min. Service Temp. °C -40 °C
Adhesive Permanent Rubber
Finish Gloss
Performance Characteristics Abrasion-resistant, Fuel/Oil-resistant, High heat resistant, Low temperature resistance, Solvent/Chemical resistance, Ultra-aggressive adhesive
Surface For smooth, textured/rough or Highly textured/Low surface energy surfaces
Label Properties Aggressive Adhesive, Heat Resistant, Low Temperature
Resistance Properties Abrasion-resistant, Chemical-resistant, Corrosion-resistant, Humidity-resistant, UV-resistant, Weather-resistant

Product Features
Product Features Shape Pyramid

Printing Specifications
Printing Specifications Print Technology Thermal Transfer
Smart Cell Yes

Compatibility
Compatibility Printer Compatibility BMP41, BMP51, BMP53, M410, M510, M511

Compliance
Compliance UNSPSC 55121612
RoHS Compliance Status Compliant with Directive 2011/65/EU and 2015/863
REACH SVHC Status Part does not contain an SVHC
REACH Candidate List Date 25 June 2025
Approval/Compliance CSA Accepted, UL Recognised

Industry Compliance
Industry Compliance CSA CSA Accepted
UL UL969
